Portable UV LED lamps adapts most advantage UV LED technology. This UV LED lamps features powerful TMUV Series a convenient white light LED to quickly switch between fluorescent inspection and flaw location. Every handheld NDT lamp is strictly tested by our senior engineer to ensure that the spectrum strictly focuses on 365-370nm and equipped with UV filter.
Features
1.100% solid state circuit ensures working properly in strong magnetic field
Switch function between UV light and White light
2.Extremely large coverage area of up to 6 inches (15 cm), with a minimum UV-A intensity of 2,000 μW/cm2
3.Unique mechanical cooling system keeps LEDs cool to maintain optimum light output during extended use
4.Rugged, modular construction allows for easy field serviceability.
5.Compliant with conformation to EMC and IEC81
Technical data
Product’s Name
Handheld UV LED lamps
Part No
9031001
Brand
TMTECK
Model type
TMUV-80
Power Source
1,220v ; 2 ,12V LI battery
UV lamp Intensity at 38CM
8000uw/cm2
Coverage area at 38cm
17cm dia
Visibale Light
0.2foot-candles (2.1lux)
Peak Wavelength
365-370nm
Power waste
less than 10W
Weight
700g(with battery)
Battery
Li-ion battery
Working hours when full charging
4.5 working hours
Power supply
12V/DC AC100-240V 1A
IP grade
IP65
Brand Name: TMTECK Power Type: Battery-Powered PRODUCTS NAME: handheld NDT UV lamp MODEL TYPE: TMUV-80
